Nikon MM-400 / MM-800

Next-Generation Measuring MicroscopesMM-400/800 Series Digital Metrology Center

Nikon is proud to present the MM-400/800 series of Measuring Microscopes, which incorporate key performance features expected in an advanced next generation measuring microscope:

• Greater Accuracy
• Digital Imaging and Vision Processing Metrology
• Larger Stage for Increased Workpiece Handling
• Non Contact Z-height Measurements
• Coordination with Data Processing Systems

The new Nikon measuring microscope can be equipped with a TTL Laser AF (universal type) and a new Focusing Aid mechanism that provides sharper and more accurate focusing. High precision Z-axis measurement is simpler than ever.

• Digital image capture using a Nikon digital camera and E-Max metrology software allows rapid measurement with precise auto edge detection.
• A fully motorized high power microscopy model is also available for digital imaging.
• By offering many options in illuminators and light sources, an expanded observation range has been achieved. These include a high-intensity white LED illuminator for brightfield observation, a universal epi-illuminator to respond to various observation needs, and a 12V-50W halogen light source.
• A motorized Z-axis movement mechanism (LM models) simplifies accurate vertical motion through the use of a dedicated controller.
• Added body strength enables the use of larger stages, such as the newly developed 12x8 stage, allowing for larger work pieces.
• Ease of operation has been greatly improved by use of various motorized controls and ergonomic design. Even the 12x8 stage is easy to manipulate despite its large size.
• Stands with the integrated MM Controller interface and the newly developed DP-E1 Data Processor or SC counters and PC-based E-Max data processing software provide excellent geometric data processing and storage.
